Create a Scanning Dashboard

Create a Scanning Dashboard

A scanning dashboard shows how many passes you scanned over recent time windows. It is a custom dashboard built from scan widgets, handy at an event where you watch entries in real time.

Build the dashboard

  1. On the dashboard, click Manage Dashboards and then create a dashboard.
  2. Name it, for example Scanning Dashboard, and save.
  3. Switch to it, then click Edit Mode.
  4. Click Add Row and choose a two column layout.
  5. Click Add Widget. Give it a headline like Scans last 5 minutes and set the window to 5 minutes. Add it to the dashboard.
  6. Click Add Widget again. Headline it Scans last 30 minutes and set the window to 30 minutes. Add it.
A scanning dashboard with scan count widgets

Your layout saves with the dashboard, so it is ready the next time you open it.
